Direct Wire
HOUSING AND CONSTRUCTION:
- Highly diffused plastic lens for even light distribution
- Steel housing
- Standard finish: premium powder coated in white
- Sleek 1” profile
LEDs:
- Manufacturer: Philips Lumileds
- Rated life: 50,000 hours
- Color temperature: 3000K; other color temperatures available for custom orders
DRIVER:
- 12W LED driver for 12”-24” fixture models; 25W LED driver for 36”-48” fixture models
- 120V input
- UL Recognized Class 2 power supply
- Type 1 Outdoor, suitable for dry and damp location
DIMMING:
- Phase control dimming
- Suitable for use with TRIAC dimmers
WIRING AND SWITCHING:
- Convertible 120V direct wire input; knockouts provided for multiple input configurations
PACKAGING:
Contents in each fixture carton:
- (1) LED fixture
- (2) Mounting screws
- (3) Wire nuts
- (1) Die cast coupler
- (1) Optional on/off rocker switch
- Instruction sheet
Need pricing, specs, or a sample? Talk to our sales team — we'll get back fast.
Additional Information
| Specification | Options |
|---|---|
| Nominal Size | 1 ft Linear | 1.5 ft Linear | 2 ft Linear | 3 ft Linear | 4 ft Linear |
| Watts | 7 W | 10 W | 12 W | 18.5 W | 23.5 W |
| Lumens | 450 lm | 675 lm | 900 lm | 1,350 lm | 1,800 lm |
